The Circular Vibrating Sieves

What are The Circular Vibrating Sieves used for?

Well. it separates liquids from solids or various particles ranging from 0,033 mm to 51 mm in a (400 mesh)

Within one Vibrowest sieve, you will incorporate 4 screen decks that can equip an easy to install five separation circular MR screener.

The standard models in which you find these ranges are sizes from 1800 mm to 440 mm

These screens can be changed fast and easy and can be equipped with systems of various cleaning ways like:

  • balls
  • CIP
  • kleeners
  • starbrush
  • the innovative ultrasonic cleaning system

These sieves also come out in different constructed materials like:

  • carbon steel
  • Stainless steel AISI 304
  • Stainless steel AISI 316

To be in accordance with the Sanitary Standards with and approved, on request, ATEX certification, FDA IQ-OQ procedure, GMP, all product areas must be polished

HOW IT OPERATES:

Though the vibrations are developed to work on both the vertical and horizontal planes it can be adjusted in all directions

With the use of a motion generator shaft with eccentric weights that are placed on flywheels on the lower and upper ends which gives the accomplished vibration.

Moving materials to the outer perimeter of the screen from the center created by the upper fly wheel’s horizontal vibrations.

A highly efficient way of creating an efficient sieving action is created by the lower flywheel by vertical vibrations as well as a tangential plane

Using a rapid, easy, and tool-free adjustment of the counterweights on each flywheel allows for modification of the pattern of vibration which suits the best vibration and sieve action of any particular product.

High screening efficiency results of both solid and liquid products are achieved because of the ability to adjust the pattern of vibration with ease.

Because of the circular vibration of the sieve and the ability to modify and adapt the motions to suit a wide variety of products and customer requirements has made it a successful tool in many industries.

The main Industry sectors which find this application useful are:

  • 1: Abrasives
  • 2: Agriculture
  • 3: Cement
  • 4: Chemical Industry
  • 5: Confectionary industry
  • 6: Cosmetics
  • 7: Dairy farming
  • 8: Diamond cutting and grinding tools
  • 9: Fodder
  • 10: Food industry
  • 11: Liquid and powder paints and pigments
  • 12: Metal processing industry
  • 13: Mining
  • 14: Petrochemical
  • 15: Pharmaceutical Industry
  • 16: Plastic materials
  • 17: Recycling and environmental
  • 18: Sand
  • 19: Spices and herbs
  • 20: Wood
